Used in marine pipelines for fresh water, air or gases, fuel oils, lubricating oils, as well as steam at 205C or below.
Dimension Table-F7312 JIS 5K | |||||||||
Size | L | FLANGE | φH | φD2 | Weight [kg] | ||||
φD | φC | N | φh | t | |||||
50 | 100 | 130 | 105 | 4 | 15 | 16 | 270 | 160 | 12.9 |
65 | 115 | 155 | 130 | 4 | 15 | 18 | 300 | 180 | 18.2 |
80 | 130 | 180 | 145 | 4 | 19 | 18 | 310 | 180 | 23.4 |
100 | 150 | 200 | 165 | 8 | 19 | 20 | 360 | 224 | 33.7 |
125 | 170 | 235 | 200 | 8 | 19 | 20 | 390 | 250 | 46.2 |
150 | 190 | 265 | 230 | 8 | 19 | 22 | 445 | 280 | 63.4 |
200 | 220 | 320 | 280 | 8 | 23 | 24 | 530 | 315 | 105 |
250 | 275 | 385 | 345 | 12 | 23 | 26 | 650 | 355 | 178 |
300 | 310 | 430 | 390 | 12 | 23 | 28 | 740 | 400 | 275 |
350 | 360 | 480 | 435 | 12 | 25 | 30 | 840 | 500 | 462 |
400 | 395 | 540 | 495 | 16 | 25 | 30 | 940 | 630 | 647 |
We supply full range of stop valves, check valves, gate valves, hose valves, storm valves, and butterlfy valves etc. Our target is to become world class ONE-STOP supplier of marine eqiupment and marine valves
